High Purity Yellow Tungsten Oxide
Preparation process of high purity yellow tungsten oxide is as follows: adjusting pH of sodium tungstate solution to 4 ~ 8 using organic or inorganic acid. After hydrothermal reaction 12 hours, filtration, concentration, crystallization and obtained seed. Under the high pressure reaction kettle, mixed solution of crystal seed and sodium acid under 200 ~ 220℃, cooled to room temperature after 12 hours. Filtering and cleaning the reaction product of, and getting the filter cake and mother liquor. Low-temperature roasting the filter cake under 350℃, and the high purity tungsten oxide products.
Yellow tungsten oxide prepared by the above process has the characteristics of fine granularity, high purity and good stability.
Related Products:
Ammonium paratungstate (APT) is an important intermediate compounds of tungsten hydrometallurgical process, appearance is white crystalline powder, insoluble in water, soluble in alcohol and ether.
Ammonium metatungstate(AMT) is an important intermediate compounds of tungsten hydrometallurgical process, appearance is white crystalline powder, solubility in water is the largest in the tungsten compounds which over 300g WO3/100ml H2O (in 25℃).
Sodium tungstate, a tungstate of sodium, is useful as a source of tungsten. It is prepared from tungsten ores used to manufacture tungsten by reducing it.
Tungstic acid refers to hydrated forms of tungsten trioxide, WO3. The simplest form, the monohydrate, is WO3.H2O, the dihydrate WO3.2H2O is also known. The solid state structure of WO3. H2O consists of layers of octahedrally coordinated WO5(H2O) units where 4 vertices are shared.
Blue tungsten oxide refers to a class of dark blue compound containing tungsten (Ⅵ) and tungsten (V) mixed valence state. Blue tungsten oxide is the product of reductant and tungsten compounds. Composition of blue tungsten oxide is complex, among which there are also intermediate oxides like WO2 and W4.
Cesium tungsten bronze is inorganic nano material with good property in absorbing near-infrared with uniform grain size and dispersibility, it has strong absorbing function in near-infrared area with wave length 800~1200nm, also has high transmittance in visible light area with wave length 380~780nm.
